Nanosecond Fiber Laser


Amonics' nanosecond fiber lasers are with high pulse energy and excellent pulse energy stability. We offer nanosecond fibers with direct modulation diode seed lasers and narrow linewidth seed lasers with external modulation.By using our high power pulse amplifier, the laser with direction modulation can have higher than mJ output energy.By using our proprietary SBS suppression technique, our narrow linewidth nanosecond pulse laser can deliver over 180 uJ pulse energy.The applications of the nanosecond laser include laser marking, laser welding, material processing, and free spacing sensing.

Narrow linewidth Nanosecond Fiber Laser (external modulation) Specifications

ANSFL-UL ANSFL-PM-UL
Operating wavelength Typ. 1540 to 1560 nm Typ. 1540 to 1560 nm
Pulse Width Typ. 100ns to 1000 ns Typ. 100ns to 1000 ns
Pulse Repetition Rate Typ. 20 KHz to 1 MHz Typ. 20 KHz to 1 MHz
Saturated Output Power up to +2 W +2 W
Pulse peak power up to (No SBS) +1kW +1kW
Linewidth Typ. 15 kHz to 200 kHz Typ. 15 kHz to 200 kHz
Output isolation Min. 30 dB Min. 30 dB
Polarization mode dispersion Typ. 0.3 dB, Max. 0.5 ps NA
Polarization Extinction Ratio NA Typ.23 dB, Min. 20 dB
Optical Fiber LMA 25/300 GDF PM LMA 25/300 GDF
Different output power models are available upon request

Nano-second Pulse Width Fiber Laser (direct modulation) Specifications

ANSFL ANSFL-PM ANSFL-10 ANSFL-PM-10
Operating wavelength Typ. 1540 to 1560 nm Typ. 1540 to 1560 nm Typ. 1540 to 1560 nm Typ. 1540 to 1560 nm
Pulse Width Typ. 10 ns to 1000 ns Typ. 10 ns to 1000 ns Typ. 5 ns to 10 ns Typ. 5 ns to 10 ns
Pulse Repetition Rate Typ. 20 KHz to 1 MHz Typ. 20 KHz to 1 MHz Typ. 100 KHz to 10 MHz Typ. 100 KHz to 10 MHz
Saturated Output Power up to +2 W +2 W +10 W +10 W
Pulse peak power up to (No SBS) +1 kW +1 kW +10 kW +10 kW
Linewidth Typ. 0.2 nm Typ. 0.2 nm Typ. 0.2 nm Typ. 0.2 nm
Output isolation Min. 30 dB Min. 30 dB Min. 30 dB Min. 30 dB
Polarization dependent gain Typ. 0.3 dB, Max. 0.5 dB NA Typ. 0.3 dB, Max. 0.5 dB NA
Polarization mode dispersion Typ. 0.3 dB, Max. 0.5 ps NA Typ. 0.3 dB, Max. 0.5 dB NA
Polarization Extinction Ratio NA Typ. 23 dB, Min. 20 dB NA Typ. 23 dB, Min. 20 dB
Optical Fiber LMA 25/300 GDF PM LMA 25/300 GDF LMA 25/300 GDF PM LMA 25/300 GDF
Different output power models are available upon request

General Parameters

unit value
Operation Temperature °C 0 to +40
Storage Temperature °C -10 to +70
Power Supply VAC 90 – 240, 47 – 63Hz
3U Rackmount Dimensions mm 485(W) x 615(D) x 150(H)
Control Keylock switch, Pump laser current
LCD Display Output power, Pump laser current, Input power (Optional)
Computer Interface RS232 (Control software & connection cable included) / Ethernet (Optional)
Protection Pump laser over heat warning
Optical Connector FC/APC, collimator or bare fiber (No output connectors for output power >2W)

Ordering Information

Product Code
ANSFL(-PM)(-UL)-aaa-bb-cc-R-dd
aaa : Pulse Width in ns
bb: Repitition Rate in kHz
cc: Average Output Power in dBm
dd: FA for FC/APC, FC for FC/UPC, SA for SC/APC, SC for SC/UPC, CL for collimator, NC for bare fiber


Key Features

High output power
High gain
Wide operation rage
Highly reliable and durable
